Mobile Scaffolding

Rolling and mobile scaffolding

Rolling scaffolding makes it possible to work at any height and at the same time ensures that those carrying out work have the greatest possible safety.

Use one now certified and TRBS 2121-1 compliant mobile scaffolding according to DIN EN 1004-1 and -2.

For optimal work safety, most of our mobile scaffolds are TÜV certified and meet the requirements of the DIN standard EN 1004 parts 1 and 2 for mobile work platforms. This corresponds to a minimum load capacity of 200kg/sqm or 150kg/sqm in the case of the AluCombine ladder frame. It should be noted that, according to DIN EN 1004, only a working height of 8 m is permitted for the assembly scaffold when working outdoors and 14 m in enclosed spaces. In addition, side protection must be attached to the three outside sides of each working level.

AluCombine - multifunctional scaffolding

The do-it-yourself scaffolding, designed as a ladder frame for working heights of up to 7m, is supplied with stable crossbars for the necessary stability. This small scaffolding can be set up on the traverse either in the middle or offset towards a wall. Tools are only necessary for initial assembly. The modular scaffolding has two tilting castors or, alternatively, 4 brakeable swivel castors for easy movement of the scaffolding.

Thanks to the vertical frames, which can be set up independently of each other in height, the scaffolding can also be used on stairs and landings. The 1.50m long and 0.5m wide decking platform is the assembly scaffolding, non-slip and weatherproof.

All struts and diagonals are attached to the ladder bars using screw connections. Tools are only required for the initial assembly of the work platform. For all subsequent uses, the scaffolding can be assembled and dismantled without tools.

With the included wall anchors, which also serve as wall spacers, installation on external walls is possible without additional ballasting.

Multifunction: Use as a leaning ladder and double ladder according to EN 131, as a small scaffolding for indoor and outdoor use or as a work platform with stair adjustment

MySelf-Tower - compact one-man scaffolding

Thanks to the sophisticated assembly method in the form of double railings, mounting hooks and 1m vertical frame, you can stand at working heights of up to 7 meters within 8 minutes.

These 1-man mobile scaffolds are ideal for anyone who is on their own or has to carry out work in cramped stairwells.

The MySelf-Tower enables safe assembly and dismantling by just one person thanks to the compact components and aluminum profiles used from level to level using mounting hooks.

Economical and ergonomic storage, transport and construction site logistics are ensured by fewer components, allowing the tool-free construction of a transport trolley that fits into existing vehicles.

Safe access to a higher platform is guaranteed thanks to pre-assembled double railings and snap-in claws. Sitting in the access hatch, the user is already in a secured area when they step onto the next higher platform thanks to the pre-assembled double railings and thus meets the applicable regulations for occupational safety in industry and trade.

Pre-assembled front and longitudinal toe boards made of aluminum to form a toe board ring enable quick installation on the decking.

Construction according to the European standard for mobile work platforms DIN EN 1004-1, for the highest quality and safety.

The rollers with a diameter of 150mm and a double brake lever enable a height adjustment of 230mm per wheel via a steel spindle, so that uneven floors can be compensated for. nnen.

The telescopic arms ensure the necessary stability even at greater working heights and can be retracted compactly for transport.

Technical data:

• Working heights: 4m, 5m, 6m and 7m
• Dimensions: 70cm x 120cm
• Load: 200kg/m²
• Rollers: Ø150mm and 230mm height adjustment
• Side protection: Double railings enable quick assembly and eliminate the need for diagonal struts
• Toeboards: compact aluminum folding construction
• Transportation: transfer carriage
• Certification: TÜV Süd according to EN 1004-1 and -2

Rollfix DIY scaffolding

The Rollfix mobile scaffold is assembled quickly and without tools using positive and non-positive clamp connections as well as attachable 1m or 2m frame system parts. When assembled, the basic framework can be easily pushed through doors using a set of castors, making it the ideal framework for interior work. The height-adjustable wheels with a diameter of 150mm enable the compensation of uneven floors of up to 230mm per wheel.

The rigid traverse enables the stability to be increased and the ballast to be applied. The V-shaped telescopic traverse offers optimum safety by increasing the standing area in the longitudinal and transverse directions. Both trusses can be set up in the middle or offset towards a wall.

With the included wall anchors, which also serve as wall spacers, installation on external walls is possible without additional ballasting.

The internal access is secured by non-slip, profiled aluminum rungs, which are firmly welded to the stems. The basic scaffolding can be increased to a working height of up to 10m in combination with the scaffolding extensions.

Each package is equipped with a platform, ensuring a maximum stage distance of 2m.

AluKlik folding scaffolding

The AluKlik is a folding scaffolding with a length of 1,800mm and a width of 750mm for the professional user. The basic folding unit enables particularly quick assembly at a low height, as it only needs to be pulled apart and the platform inserted. The hinge of the basic folding unit is self-locking. In this state, the scaffolding can be driven through room doors.

In the basic version, the scaffolding is delivered with outriggers, but can also be optionally equipped with wall anchors.

Every folding frame that has castors for manual movement is equipped with locks on all castors to ensure a secure stand at all times. As standard, the wheels have a diameter of 150mm, a double brake lever and a steel spindle for height compensation of up to 230mm. If ballast weights are required for the mobile scaffolding due to its design and height, these are included in the scope of delivery. You will find detailed ballasting specifications for your mobile scaffold in the assembly instructions.

Technical data:

• Scaffolding length: 1.80m; Scaffolding width: 0.75m or 1.30m.
• Working height from 3m to 14m.
• Guaranteeing stability via wall anchors or brackets.
• According to new EN 1004; Scaffolding class 3 (loadable up to 200 kg/m²).
• Holder and rung diameter 50.6mm.

AluDeck work platform with the extra large work surface

Mobility for all cases

With a mobile scaffold you are able to ensure quick and efficient work on or in buildings for all craft work, as it can be easily assembled and dismantled and ensures a secure footing. Our mobile scaffolding also offers plenty of space for the necessary work materials and can be stored or transported in a particularly space-saving manner. As a folding scaffolding, it can be folded up extra quickly.

Rolling scaffolding for working at any height

For work on external walls as well as inside the building, you will find lightweight aluminum assembly scaffolding in our range, which can be set up anywhere in just a few steps. Thanks to the use of fewer individual parts with both positive and non-positive connections, our folding scaffolding is as safe as it is easy to use. With various selectable working heights, as well as additional extensions available on many models, the working height can be flexibly adjusted to suit your needs without the rolling scaffold losing any of its safety.

Be way ahead of your work with a mobile scaffolding

With the very resilient mobile towers, remarkable working heights can be achieved without any problems. With scaffolding heights of up to 14m, our mobile scaffolding can also be used particularly flexibly in all areas. With a mobile scaffolding, flexibility is guaranteed at work at any time. No more tedious assembly and dismantling, but rather quick movement of the work platform saves a significant amount of time and therefore money. Short-term plan changes are no longer a problem with a mobile scaffolding from ALTEC.

A stable working platform even at lofty heights

Regardless of whether it is used as a maneuverable assembly scaffold or as a folding scaffold that can be quickly assembled and dismantled, the scaffold stands securely. But not only is the mobile scaffolding safe, but also the people working on it. You will receive the mobile scaffolding of your choice, usually with a durable phenolic resin screen printing plate as a platform. The non-slip and weatherproof surface also serves as a safe standing surface and as a storage area for work utensils. Depending on the model chosen, the scaffolding and thus the platform have a width of up to 1.35m for comfortable working at any height.
